Description

Mid-wheel drive design delivers outstanding manoeuvrability in tight, compact spaces and a smooth and stable ride both indoors and outdoors even over rough terrain .
Patented obstacle climbing suspension that works.
Dual in-line motors enhanced efficiency torque, range and performance.
Height and width adjustable armrests on the new contoured seat.
Height adjustable four post seat with reclining back rest.
Swing back joystick mount is standard.
Other options available are electric seat lift, rear attendant controls, optional seating & leg rests.

Additional information

Mid-wheel drive design delivers outstanding manoeuvrability in tight, compact spaces and a smooth and stable ride both indoors and outdoors even over rough terrain .
Patented obstacle climbing suspension that works.
Dual in-line motors enhanced efficiency torque, range and performance.
Height and width adjustable armrests on the new contoured seat.
Height adjustable four post seat with reclining back rest.
Swing back joystick mount is standard.
Other options available are electric seat lift, rear attendant controls, optional seating & leg rests.

Overall Length	900 mm
Overall Width	690 mm
Min Overall Height	1270 mm
Max Overall Height	1270 mm
Min Seat Width	510 mm
Max Seat Width	510 mm
Min Seat Depth	460 mm
Max Seat Depth	460 mm
Min Floor To Seat Height	350 mm
Max Floor To Seat Height	450 mm
Min Seat Height from Deck	530 mm
Max Seat Height from Deck	580 mm
Turning Radius	530 mm
Backrest Height	510 mm
Castor Diameter	152 mm
Range	32 km
Max Speed	8 km/h
Gradient	8 °
Ground Clearance	56 mm
Battery	12v/55ah x 2pcs Ah
Motor Size	200W/575W hp
Controller	PG VR2 50A
Charger	5Amp A
Product Weight	106 kg
Total Weight Without Battery	76 kg
Max User Weight	205 kg
