Description

Mid-wheel drive design delivers outstanding manoeuvrability in tight, compact spaces and the superior adjustable suspension design delivers a smooth and stable ride both indoors and outdoors, even over tough terrain.
Transit Occupied Certificate.
Patented obstacle climbing suspension that works.
Dual in-line motors enhanced efficiency torque, range and performance.
Height and width adjustable armrests on the new contoured seat.
Height adjustable four post seat with width and depth adjustment (R601).
Crash tested tie down points.
Other options available are head rest, rear attendant controls, optional leg rests rests .

Additional information

Mid-wheel drive design delivers outstanding manoeuvrability in tight, compact spaces and the superior adjustable suspension design delivers a smooth and stable ride both indoors and outdoors, even over tough terrain.
Transit Occupied Certificate.
Patented obstacle climbing suspension that works.
Dual in-line motors enhanced efficiency torque, range and performance.
Height and width adjustable armrests on the new contoured seat.
Height adjustable four post seat with width and depth adjustment (R601).
Crash tested tie down points.
Other options available are head rest, rear attendant controls, optional leg rests rests .

Overall Length	900 mm
Overall Width	690 mm
Min Overall Height	1000 mm
Max Overall Height	1000 mm
Min Seat Width	460 mm
Max Seat Width	560 mm
Min Seat Depth	460 mm
Max Seat Depth	560 mm
Min Floor To Seat Height	320 mm
Max Floor To Seat Height	370 mm
Min Seat Height from Deck	440 mm
Max Seat Height from Deck	490 mm
Turning Radius	530 mm
Backrest Height	460 mm
Castor Diameter	152 mm
Range	32 km
Max Speed	8 km/h
Gradient	8 °
Ground Clearance	56 mm
Battery	12v/55ah x 2pcs Ah
Motor Size	200W/575W hp
Controller	PG VR2 50A
Charger	5Amp A
Product Weight	111 kg
Total Weight Without Battery	78 kg
Max User Weight	205 kg
