Features

• Push to lock standard lock with optional drum brake kits
• Solid 23” drive wheels. Pneumatic option is also available
• Solid 7.5” castors
• Accessories: elevating leg rest with calf support, stump support, headrest and drum brake conversion kit
• Removable and washable foam seating and backrest pad
• Quick flip-up anti-tippers mechanism
• Adjustable Centre of Gravity
• Height Adjustable Built-in push handles

• Footplates are angle adjustable
• Push to lock brakes
• Removable or flip away, anti-tip wheels
• Swing away leg rests
• Adaptable backrest to suit other backrest options
• Built-in backrest pocket
• Adjustable, Swing Away & Removable leg rests
• Flip Back & Removable Armrests
• Tension Adjustable Backrest
• DVA approved

  Specifications

• Weight Capacity: 136kg
• Seat Width: 40 cm, 46 cm, 49 cm
• Footrest Extender: 6 cm Footrest extender/joiner
• Extendable Footrests: 10.5 – 15.5 cm
• Armrest Height: 18 – 26 cm (2 cm increments)
• Arm Pad Position: 33 – 45 cm (4 cm increments)
• Anterior Seat Height: 42, 44.5, 45, 47, 47.5, 50 cm
• Posterior Seat Height: 41, 43, 45, 47, 47.5, 50 cm
• Seat Depth: 40, 42.5, 45, 47.5, 50 cm
• Backrest Height: 40 – 46 cm (2cm increments)
• Backrest Angle: 85° – 105° (5° increments)
• Lower Leg Length: 40 – 48 cm (2 cm increments)
• Footplate Length Adjustment: 10.5 -15.5 cm
• Overall, Height: 85 – 93 cm
• Overall Length: 103 cm
• Length excluding Footrest: 90 cm
• Overall Width: is equal to “seat width + 15 cm”
• Width Folded: 34 cm
• Gross Weight: from 15.5 kg
• Net Weight: from 9 kg
